Italy Style Supermarket Shelf
Model: FDKL-S0225
Italy style supermarket shelf features:
- Pitch 25mm, more flexible for adjustment.
- Detachable base legs make transportation easier.
- Heavy loading and economical.
- Small height for shelf and central back panel design maximizes display space.
Product Description
Italy Style Supermarket Shelf
Hongda supermarket shelves are widely used in various supermarkets, stores, grocery stores, etc. Our supermarket shelves are strictly in accordance with the quality requirements, with fine workmanship and first-class quality, to provide you with the best pre-sales and after-sales services, and relieve your worries during the use of the shelves. Hongda- a professional shelf manufacturer, sells various supermarket shelves with factory prices, and at the same time provides you with a complete turnkey service, designing and manufacturing exclusive shelves according to your requirements.
If you are interested in our medium duty storage rack, you can contact us via email: info@hdshelf.com or whatsApp: +86 13962497718.
Parameter
| No,Basic Components/lmage | Dimensions (mm) | ||
|---|---|---|---|
| 1. Upright |  | Cross Sections | 30*80 |
| Height | 900~2800 | ||
| Material Thickness | 2.5 | ||
| 2. Base Leg |  | Depth | 370 |
| Height | 130 | ||
| Material Thickness | 1.5 | ||
| 3. Center Back Panel |  | Length | 870/970/1170 |
| Height | 200/300/400 | ||
| Material Thickness | 0.7/0.8 | ||
| 4. Top Cover |  | Length | 870/970/1170 |
| Width | 80 | ||
| Material Thickness | 1.5 | ||
| 5. Plinth |  | Length | 890/990/1190 |
| Height | 75 | ||
| Material Thickness | 0.6 | ||
| 6. Shelf |  | Length | 898/998/1198 |
| Width | 344/394/444 | ||
| Material Thickness | 0.7/0.8 | ||
| 7. Bracket |  | Length | 300/350/400 |
| Material Thickness | 2.5/3.0 | ||
